GridTask 100-277V LED Ceiling Grid Lighting System

GridTask LED linear has added a unique combination of LED module and T-Grid bracket. Featuring a new generation of ceiling lighting solutions, GridTask delivers up to 130 lm/w. GridTask is available in 2′ / 10W and 4′ / 20W units, providing glare-free and uniform light distribution.

100 – 277V
3500K, 4000K
0-10 dimming (DIVA-DVTV (Lutron), NOVA-NTSTV-TV)
2′ (10W) or 4′ (20W) grid
Replaces 9/16″ (G2) and 15/16″ (G1) T-Bar Grids
Low profile – 1/2″
120° beam spread
Fixture includes grid
Suitable for damp location
80+ CRI
LM70
130 LPW Efficacy
IC Rated
UL listed
5 year warranty

Ordering Information

Catalog No.	Dimensions	Wattage	Lumens	Color Temp.	Finish
TGB-2-35-G1	2′ grid for 15/16″ std. grid	10W	1300	3500K	Frosted White
TGB-2-35-G2	2′ grid for 9/16″ std. grid	10W	1300	3500K	Frosted White
TGB-2-40-G1	2′ grid for 15/16″ std. grid	10W	1300	4000K	Frosted White
TGB-2-40-G2	2′ grid for 9/16″ std. grid	10W	1300	4000K	Frosted White
TGB-4-35-G1	4′ grid for 15/16″ std. grid	20W	2600	3500K	Frosted White
TGB-4-35-G2	4′ grid for 9/16″ std. grid	20W	2600	3500K	Frosted White
TGB-4-40-G1	4′ grid for 15/16″ std. grid	20W	2600	4000K	Frosted White
TGB-4-40-G2	4′ grid for 9/16″ std. grid	20W	2600	4000K	Frosted White
